Unique Moving Head LED Display X Rover

A groundbreaking design.

Video,lighting and rotating motor combined,make your stage full of magic.

The maximum rotation angle is 540°,and 100°/s speed rotation speed.

Advanced silent control technology,no noise at work.

Inquiry now Brochure Download

Unique Design, Multiple Applications

Integrated with video,lighting and movement 3-in-1 functions,suitable for TV applications and all video recorded events.

Perfect Combination of Art and Technology

Intelligent Control Design

Color touch screen, easy to operate

Super Quiet and Smooth Movements

High-resolution stepper motors operated via microprocessors ensure extreme accuracy and smooth movements.

High Brightness and Waterproof for Outdoor

Aluminum profile and magnesium alloy die-casting body,light weight and reliable.

Waterproof design for outdoor.

Modular Design, Easy Maintenance

Quick locks make it easy to dismantle and install the LED panel and spot lights.

All In One, Exceed Expectation

X/XO Panels can be used with X Rover Plus, simple panel and cost effective but multiple options.

Specification

Model

X Rover

LED Screen

Pixel pitch

3.9mm

Resolution

128x128Pixels

Screen size

500x500mm

Brightness

4000 nits

Screen Power(Max)

200W

View angle(Hor/Vert)

160°/ 160°

Refresh rate

3840Hz

Gray scale

14bit

Signal input

HDMI,DVI

Control system

Nova

Maintenance

Front

Led Spot

Luminaire

LED Pitch

88mm

Light souce

15 Watt RGBW 4-in-1

Beam aperture

8°(15°Optional)

Lens

32mm diameter, PMMA Optics

Strobe

1-20 flashes per sceond

Dimmer

16 bits

Working Voltage

DC 12V

Power consumption（Max）

360W

Body material

Die-cast Aluminum profile

Life span

≥50000 H

Movement

Pan:540°, Tilt:120°; 100°/s

Control

DMX512,RDM, Art-Net, Scan Protocal

Others

DMX channels

32/112

Body material

Alumnium alloy，Nylon+Fiber

Weather protection

IP65

Power input

100~240VAC/50~60Hz

Power consumption（Max）

550W

Size

600x600x480 mm

Flight Case

645x710x730mm

Net Weight

32kg

Operating temperature

-40~+60℃

Storage temperature

-40~+60℃

Certification

CE,FCC,RoHS

Accessories
